GenComm Page 2 - Modem Settings
1. Modem control strings can contain any ASCII characters and are padded with spaces (ASCII
0x20), NULL terminators are not used.
2. Each string is automatically suffixed with <CR><LF> so these should not be included in the
string, strings are not automatically prefixed with ‘AT’ so these must be included when required.
3. A string may contain a meta character consisting of 3 tildes (~~~) which indicates that a pause
of 1 second should be introduced before the rest of the string is sent to the modem. This meta
character may be repeated if longer delays are required. The tildes will not be sent to the
modem.
4. If a dialling string contains only spaces (ASCII 0x20) it will not be used in the dialling sequence.
5. The meaning of the modem’s mode is described in the table below.
6. The modem dial back string can be used by a master to call the slave device, it is never used
by the slave device.
7. The SMS enable flag enables the transmission of SMS messages over a GSM modem, the
method of transmission, circumstances that trigger a transmission and contents of the
messages are not defined in this standard.
8. The SMS message centre number and recipient number are in the same format as the other
modem control strings and are only used when the SMS system is activated by the SMS
enable flag, their use is not defined in this standard.
Registers
These are all read/write registers.
Register
offset
Name Min
value
Max
value
Scale
factor
Units Bits/
sign
0 Modem mode 0 16
1 Connect delay time 1 60 1 Secs 16
2 Number of retries on each
number
0 99 1 16
3 Delay between retries 0 60 1 Secs 16
4 Delay before repeat cycle 0 3600 1 Secs 16
5 Short message service (SMS)
enabled
No Yes 16
6-63 Reserved
64-79 First dialling string ASCII ASCII 256
80-95 Second dialling string ASCII ASCII 256
96-111 Third dialling string ASCII ASCII 256
112-127 Fourth dialling string ASCII ASCII 256
128-143 Modem initialisation string - not
auto-answer
ASCII ASCII 256
144-159 Modem initialisation string - auto-
answer
ASCII ASCII 256
160-175 Modem hang-up string ASCII ASCII 256
176-191 Modem dial back string ASCII ASCII 256
192-207 Short message service (SMS)
message center number
ASCII ASCII 256
208-223 Short message service (SMS)
recipient number
ASCII ASCII 256
224-255 Reserved for more modem
strings
512
To Next Page
