Registers
These are all read only registers.
Register
offset
Name Min value Max value Scale
factor
Units Bits/ sign
0 Manufacturer code 0 65534 1 16
1 Model number 0 65534 1 16
2-3 Serial number 0 99999999
9
1 32
4 Control mode 0 65535 1 16
5 Unimplemented 0xFFFF 0xFFFF 16
6 Control unit not
configured
No Yes 16/16
Unimplemented 0 0 15/16
Control unit failure No Yes 14/16
Shutdown alarm active No Yes 13/16
Electrical trip alarm
active
No Yes 12/16
Warning alarm active No Yes 11/16
Telemetry alarm flag Not active Active 10/16
Satellite telemetry
alarm flag
Not active Active 9/16
No font file No Yes 8/16
Unimplemented 0 0 1/16-7/16
7 S.M. 1 status 0 3 16/16-
15/16
S.M. 2 status 0 3 14/16-
13/16
S.M. 3 status 0 3 12/16-
11/16
S.M. 4 status 0 3 12/16-
11/16
Reserved
Reserved
Reserved
Reserved
8-9 String checksum 0 0xFFFFFF
FF
32
10 S.M. 1 timer 0 65534 1 Secs 16
11 S.M. 2 timer 0 65534 1 Secs 16
12 S.M. 3 timer 0 65534 1 Secs 16
13 Reserved
14 Reserved
15 Reserved
16 Reserved
17 Reserved
18-255 Reserved
