Deep Sea Electronics Plc 5220 User Manual

55xGenComm1_29
44
Alarm condition codes
Condition Meaning String to
display
Extra info
0 Disabled digital input None An alarm that is fitted but
disabled by the configuration of
the slave device
1 Not active alarm None
2 Warning alarm Active string
3 Shutdown alarm Active string
4 Electrical trip alarm Active string
5-7 Reserved
8 Inactive indication (no string) None An indication that does not
require a message to be
displayed when inactive.
9 Inactive indication (displayed
string)
Inactive string An indication that requires a
message to be displayed when
inactive (“dual indication” input
type)
10 Active indication Active string
11-14 Reserved
15 Unimplemented alarm None An alarm that is not
implemented on the control unit
