Register offset Name Min value Max value Bits/ Sign
10 Mains low frequency 0 15 13/16-16/16
Mains high frequency 0 15 9/16-12/16
Mains failed 0 15 5/16-8/16
Mains phase rotation wrong 0 15 1/16-4/16
11 Generator phase rotation wrong 0 15 13/16-16/16
Maintenance due 0 15 9/16-12/16
Clock not set 0 15 5/16-8/16
Local LCD configuration lost 0 15 1/16-4/16
12 Local telemetry configuration lost 0 15 13/16-16/16
Control unit not calibrated 0 15 9/16-12/16
Modem power fault 0 15 5/16-8/16
Generator short circuit 0 15 1/16-4/16
13 Failure to synchronise 0 15 13/16-16/16
Bus live 0 15 9/16-12/16
Scheduled run 0 15 5/16-8/16
Bus phase rotation wrong 0 15 1/16-4/16
14 Priority selection error 0 15 13/16-16/16
Multiset communications (MSC)
data error
0 15 9/16-12/16
Multiset communications (MSC) ID
error
0 15 5/16-8/16
Multiset communications (MSC)
failure
0 15 1/16-4/16
15 Engine management bus error 0 15 13/16-16/16
Unimplemented 15 15 9/16-12/16
Unimplemented 15 15 5/16-8/16
Unimplemented 15 15 1/16-4/16
16-32 Unimplemented 15 15
33-127 Reserved
128 Number of Digital inputs 0 128 16
129 Digital input 1 0 15 13/16-16/16
Digital input 2 0 15 9/16-12/16
Digital input 3 0 15 5/16-8/16
Digital input 4 0 15 1/16-4/16
130 Digital input 5 0 15 13/16-16/16
Digital input 6 0 15 9/16-12/16
Digital input 7 0 15 5/16-8/16
Digital input 8 0 15 1/16-4/16
131 Digital input 9 0 15 13/16-16/16
Reserved
Reserved
Reserved
NOTE:- The inactive strings are only required for “dual indication” input types, in all other
cases they will contain 32 spaces
NOTE:- Alarm blocks relating to mains monitoring are only available on the 555
module
