Deep Sea Electronics Plc 5220 User Manual

55xGenComm1_29
42
GenComm Page 8 - Alarm Conditions
1. Each alarm has 2 strings in pages 32-95, which can be displayed on the monitoring system if
required. The alarm code specifies which string it is appropriate to display.
2. The contents of alarm strings will never change while the slave device is operating so a copy
can be held by the master to minimise data traffic.
Registers
These are all read only registers.
Register offset Name Min value Max value Bits/ Sign
0 Number of named alarms 47 128 16
1 Emergency stop 0 15 13/16-16/16
Low oil pressure 0 15 9/16-12/16
High coolant temperature 0 15 5/16-8/16
Reserved 0 15 1/16-4/16
2 Under speed 0 15 13/16-16/16
Over speed 0 15 9/16-12/16
Fail to start 0 15 5/16-8/16
Fail to come to rest 0 15 1/16-4/16
3 Loss of speed sensing 0 15 13/16-16/16
Generator low voltage 0 15 9/16-12/16
Generator high voltage 0 15 5/16-8/16
Generator low frequency 0 15 1/16-4/16
4 Generator high frequency 0 15 13/16-16/16
Generator high current 0 15 9/16-12/16
Generator earth fault 0 15 5/16-8/16
Generator reverse power 0 15 1/16-4/16
5 Air flap 0 15 13/16-16/16
Oil pressure sender fault 0 15 9/16-12/16
Coolant temperature sender fault 0 15 5/16-8/16
Reserved 0 15 1/16-4/16
6 Fuel level sender fault 0 15 13/16-16/16
Magnetic pickup fault 0 15 9/16-12/16
Loss of AC speed signal 0 15 5/16-8/16
Charge alternator failure 0 15 1/16-4/16
7 Low battery voltage 0 15 13/16-16/16
High battery voltage 0 15 9/16-12/16
Low fuel level 0 15 5/16-8/16
High fuel level 0 15 1/16-4/16
8 Generator failed to close 0 15 13/16-16/16
Mains failed to close 0 15 9/16-12/16
Generator failed to open 0 15 5/16-8/16
Mains failed to open 0 15 1/16-4/16
9 Mains low voltage 0 15 13/16-16/16
Mains high voltage 0 15 9/16-12/16
Unimplemented 15 15 5/16-8/16
Unimplemented 15 15 1/16-4/16
