GenComm Pages 32 to 95 - Alarm Strings
1. Each string consists of 32 Unicode characters with the first character at the lowest register
address, NULL terminators are not used.
2. There are 2 strings corresponding to each alarm, refer to the alarm conditions page for details
of their use.
3. The contents of these strings will never change while the slave device is operating so a copy
can be held by the master to minimise traffic. The contents of digital input 1-9 strings are
defined in the module’s main configuration. These can only be changed using the P810 for
Windows configuration software.
4. Reading the string for an unimplemented alarm will return 32 spaces (Unicode 0x0020).
5. The inactive string for an alarm may not be used, in which case it will return 32 spaces
(Unicode 0x0020).
6. You would not normally read these strings without first establishing that the string
you wish to read is required. Ie the Example in the section entitled ‘GenComm Page 8
- Alarm Conditions’ details reading the alarm status from the module, and identifying which
alarm strings to read from the above string table.
Registers
These are read only registers.
Page Register offset Name Bits
32 0 Emergency stop inactive string 512
32 Emergency stop active string 512
64 Low oil pressure inactive string 512
96 Low oil pressure active string 512
128 High coolant temperature inactive string 512
160 High coolant temperature active string 512
192 Reserved 512
224 Reserved 512
33 0 Under speed inactive string 512
32 Under speed active string 512
64 Over speed inactive string 512
96 Over speed active string 512
128 Fail to start inactive string 512
160 Fail to start active string 512
192 Fail to come to rest inactive string 512
224 Fail to come to rest active string 512
34 0 Loss of speed sensing inactive string 512
32 Loss of speed sensing active string 512
64 Generator low voltage inactive string 512
96 Generator low voltage active string 512
128 Generator high voltage inactive string 512
160 Generator high voltage active string 512
192 Generator low frequency inactive string 512
224 Generator low frequency active string 512
35 0 Generator high frequency inactive string 512
32 Generator high frequency active string 512
64 Generator high current inactive string 512
96 Generator high current active string 512
128 Generator earth fault inactive string 512
160 Generator earth fault active string 512
192 Generator reverse power inactive string 512
224 Generator reverse power active string 512
