GenComm Page 26 - State Machine Name Strings
1. Each string consists of 32 Unicode characters with the first character is at the lowest register
address, NULL terminators are not used.
2. The strings contain the names of the state machines that are implemented in a particular slave
device.
3. The contents of these strings will never change while the slave device is operating so a copy
can be held by the master to minimise traffic.
4. Reading the string for a unimplemented state machine will return 32 spaces (Unicode 0x0020).
Registers
These are read only registers.
Register offset Name Bits
0 S.M. 1 name string 512
32 S.M. 2 name string 512
64 S.M. 3 name string 512
96 – 255 Reserved
