Deep Sea Electronics Plc 5220 User Manual

55xGenComm1_29
60
Page Register offset Name Bits
42 0 Generator phase rotation wrong inactive string 512
32 Generator phase rotation wrong active string 512
64 Maintenance due inactive string 512
96 Maintenance due active string 512
128 Clock not set inactive string 512
160 Clock not set active string 512
192 Local LCD configuration lost inactive string 512
224 Local LCD configuration lost inactive string 512
43 0 Local telemetry configuration lost inactive string 512
32 Local telemetry configuration lost active string 512
64 Calibration lost inactive string 512
96 Calibration lost active string 512
128 Modem power fault inactive string 512
160 Modem power fault active string 512
192 Generator short circuit inactive string 512
224 Generator short circuit active string 512
44 0 Failure to synchronise inactive string 512
32 Failure to synchronise active string 512
64 Bus live inactive string 512
96 Bus live active string 512
128 Scheduled run inactive string 512
160 Scheduled run active string 512
192 Bus phase rotation wrong inactive string 512
224 Bus phase rotation wrong active string 512
45 0 Priority selection error inactive string 512
32 Priority selection error active string 512
64 MSC data error inactive string 512
96 MSC data error active string 512
128 MSC ID error inactive string 512
160 MSC ID error active string 512
192 MSC failure inactive string 512
224 MSC failure active string 512
46 0 Engine management bus error inactive string 512
32 Engine management bus error active string 512
64 Reserved 512
96 Reserved 512
128 Reserved 512
160 Reserved 512
192 Reserved 512
224 Reserved 512
47-63 Reserved
64 0 Digital input 1 inactive string 512
32 Digital input 1 active string 512
64 Digital input 2 inactive string 512
96 Digital input 2 active string 512
128 Digital input 3 inactive string 512
160 Digital input 3 active string 512
192 Digital input 4 inactive string 512
224 Digital input 4 active string 512
65 Digital input 5-8 strings
66 Digital input 9-12 strings
67-95 Reserved
