DSE Model 5320 Automatic Mains Failure & Instrumentation System Operators Manual
24 Part No. 057-014 5320 OPERATING MANUAL ISSUE 5.1 18/06/2007 ADM
5.2.1 INSTRUMENT PAGE CONTENT
• Engine speed
• Oil Pressure
• Coolant temperature
• Engine Hours Run
• DC Battery Voltage
• Charge alternator voltage
• Modem status (GSM)
• Generator AC Voltage Line-Neutral
• Generator AC Voltage Line-Line
• Generator Line Current
(Displays load current when CTs are located
in the load feed, and the module is suitably
configured).
(Displays mains load when CTs are located in
the load feed, and the module is suitably
configured).
• Generator Output
• Number of starts
• Fuel level (%)
• Mains (Utility) AC Voltage Line-Neutral
• Mains (Utility) AC Voltage Line-Line
• Mains (Utility) Frequency (Hz)
If enhanced instrumentation is selected, the following instrumentation will become
available, if supported by the engine manufacturer.
• Engine oil temperature
• Inlet manifold temperature
• Coolant pressure
• Fuel pressure
• Fuel consumption
• Total fuel used
• Turbo pressure
To Next Page
