DSE Model 5320 Automatic Mains Failure & Instrumentation System Operators Manual
20 Part No. 057-014 5320 OPERATING MANUAL ISSUE 5.1 18/06/2007 ADM
5 DESCRIPTION OF CONTROLS
The following section details the function and meaning of the various controls on the module.
Scroll Down Next page Configurable LEDs
Deep Sea Electronics
Model 5220
O
I
+
AUTO
i
Warming 10s
L-N 240V 0A 50Hz
L-L 415V 0kW
RUNNING IN AUTO
Stop Manual Test Auto Mute/Lamp
Test
Start
FIG 2A
To Next Page
