DSE Model 5320 Automatic Mains Failure & Instrumentation System Operators Manual
50 Part No. 057-014 5320 OPERATING MANUAL ISSUE 5.1 18/06/2007 ADM
12 FACTORY DEFAULT CONFIGURATION
In the tables below, the icon
# indicates an item that can be adjusted from the module’s front panel editor.
Absence of the
# icon beside an item means that adjustment of this parameter is only possible using the 5xxx
series configuration software in conjunction with the P810 interface.
For further details on adjustment from the front panel editor, see the section entitled “Front panel configuration”
elsewhere within this manual.
Module settings Value
Base module 5320 automatic mains failure module
Miscellaneous settings Value
Two lines of text
(Configuration description)
Blank
Alternator fitted Yes
Poles 4
Magnetic pickup fitted No
CAN enabled No
AC System 3 phase, 4 wire
VT Ratio Disabled
Mains failure detection Enabled
Number of start attempts 3
Enable fast loading feature No
Immediate mains dropout Disabled
Sleep in STOP mode No
All warnings are latched No
Input settings – Analogue | Oil pressure Value
Low oil pressure input type VDO 10 bar
Trip Return
Low oil pressure pre-alarm
#
1.17 Bar 17.0 PSI 1.24 Bar 18.0 PSI
Low oil pressure shutdown
#
1.03 Bar 14.9 PSI N/A
Input settings – Analogue | Coolant
temp
Value
High coolant temp input type VDO 120 degrees C
Trip Return
High coolant temp pre-alarm
#
115°C 239°F 110°C 230°F
High coolant temp shutdown
#
120°C 248°F N/A
Low coolant temp pre-alarm
#
65°C 149°F 66°C 151°F
Input settings – Analogue | Fuel level Value
Fuel level input type Not Used
