DSE Model 5320 Automatic Mains Failure & Instrumentation System Operators Manual
Part No. 057-014 5320 OPERATING MANUAL ISSUE 5.1 18/06/2007 ADM 51
Input settings - Digital Value
1 Remote start Close to activate
2 Lamp test Close to activate
3 User configured Close to activate, Warning Active from safety on
4 User configured Close to activate, Shutdown Always active
5 User configured Close to activate, Shutdown Active from safety on
6 User configured Close to activate, Electrical trip Always active
NOTE:- Inputs set to ‘User configured’ have an extra text box to allow the user to type in a
description.
Output settings – Relay Value
1 Energise Preheat (during pre-heat timer)
2 Energise Common alarm
3 Energise System in auto mode
4 Energise Close generator
5 De-energise Close mains
Output settings – Expansion
A
Value
1 Energise System in auto mode
2 Energise Fail to start
3 Energise Generator available
4 Energise Delayed alarms armed
5 Energise Combined under / over freq. Shutdown
6 Energise Combined under / over voltage shutdown
7 Energise Cooling timer in progress
8 Energise Mains failure
Output settings – Expansion
B
Value
1 Energise Output not used
2 Energise Output not used
3 Energise Output not used
4 Energise Output not used
5 Energise Output not used
6 Energise Output not used
7 Energise Output not used
8 Energise Output not used
LED indicator settings Value
1 Lit Remote start on load
2 Lit Lamp Test
3 Lit System In Auto
4 Lit Common alarm
