DSE Model 5320 Automatic Mains Failure & Instrumentation System Operators Manual
58 Part No. 057-014 5320 OPERATING MANUAL ISSUE 5.1 18/06/2007 ADM
14.3 5320 IDMT TRIPPING CURVES (TYPICAL)
5320 Delayed over-current protection
1
10
100
1000
10000
100000
1000000
123
Current as a multiple of the trip-point setting (tripping curve = 36)
Tripping time in seconds
