8
TV
HDMI
OPTICAL
AUX
BLUETOOTH
HEOS
Several source colors indicate the audio bitstream for non-streaming inputs.
PCM CONTENT DOLBY SIGNAL DTS SIGNAL
Sound Bar Indicators and Status Lights
NOTE: “TV” Input is set as HDMI OUT (eARC / ARC) by default, but the input source is congurable
by going to the “TV Input” setting in the “My Devices” menu within the HEOS App.
1 2 3 4 5
Visual Indicator LEDs
Status LED
Source Indication
Below is a table showing the source indicators.
