MAINTENANCE NOTICE
NM-275 index 09 Page 30/50 September 2021
8.5 Changing tolerances
1) Go to the Tolerance menu by pressing 3 times the button
2) When the Tolerance LED is flashing, confirm by pressing the button for at least 3 seconds.
3) The current tolerance is displayed on the front LED. Press the button several times to change the tolerance
until the desired one is found.
Button
Effect
LED column
RGB
LED
Change the tolerance to ± 1 mm
M Flash
T steady
off
Change the tolerance to ± 1.6 mm
A Flash
T steady
off
Change the tolerance to ± 2.5 mm
S Flash
T steady
off
Change the tolerance to ± 5 mm
S Flash
A Flash
M Flash
T steady
off
Change the tolerance to ± 10 mm
S Flash
A Flash
T steady
off
3 x
3 sec.
