MAINTENANCE NOTICE
NM-275 index 09 Page 6/50 September 2021
MAINTENANCE NOTICE SORIO Signalling unit
3 INTRODUCTION
The new generation Sorio® control unit, intelligent, easy to use and set up, is adaptable to all types of valves.
Available in digital, AS-i, IO-Link versions.
The SORIO signalling unit can be fitted to Normally Closed (NC), Normally Open (NO), double acting valves.
It is available in 1EV, 2EV, 3EV and Double effect monostable and bistable configurations.
The connection is made through a cable gland or M12 connector.
List of available versions:
• 1EV Digital, Cable gland.
• 1EV Digital, M12 connector, 8 Poles.
• 1EV AS-i, Cable gland.
• 1EV AS-i, M12 connector, 4 Poles.
• 1EV IO Link, M12 connector, 4 Poles.
• 2EV Digital, Cable gland.
• 2EV Digital, M12 connector, 8 Poles.
• 2EV AS-i, Cable gland.
• 2EV AS-i, M12 connector, 4 Poles.
• 2EV IO Link, M12 connector, 4 Poles.
• 3EV Digital, Cable gland.
• 3EV Digital, M12 connector, 8 Poles.
• 3EV AS-i, Cable gland.
• 3EV AS-i, M12 connector, 4 Poles.
• 3EV IO Link, M12 connector, 4 Poles.
• 1EV Double Effect Monostable Digital, Cable gland.
• 1EV Double Effect Monostable Digital, M12 connector, 8 Poles.
• 1EV Double Effect Monostable AS-i, Cable gland.
• 1EV Double Effect Monostable AS-i, M12 connector, 4 Poles.
• 1EV Double Effect Monostable IO Link, M12 connector, 4 Poles.
• 1EV Double Effect Bistable Digital, Cable gland.
• 1EV Double Effect Bistable AS-i, Cable gland.
• 1EV Double Effect Bistable IO Link, M12 connector, 4 Poles.
