9.2 Sorio® unit 1EV spare parts list
Rep
Description
Quantity
Reference
1
Sorio
®
unit plastic cover
1
7162068
1a
Sorio
®
unit stainless steel cover
1
7162046
2a
1EV Digital - IO-Link module
1 depending on
configuration
7162001
2b
1EV AS-I 3.0 module
1 depending on
configuration
7162003
1EV AS-I 2.1 module
7162220
1EV AS-I 2.0 module
7162221
3
Solenoid valve 3-2_NC Common exhaust 24VDC Lock ¼
turn
1
7162257
4a
1EV Sorio
®
base
1 depending on
configuration
7162030
4b
Sorio
®
1EV base - M12 4-pole connector
1 depending on
configuration
7162151
4c
Sorio
®
1EV base - M12 8-pole connector
1 depending on
configuration
7162152
5
M16 x 1.5 cable gland
1 depending on
configuration
7162139
6a
M12 cord 3-pole 1EV-3EV AS-i IO-Link
1 depending on base
Included in base 4b
6b
8-pole M12 cord 1EV Digital
1 depending on base
Included in base 4c
7
Ø6 straight snap fitting
1
7009065
8
1/8'' Gas exhaust plastic plug
2
7002496
9
O-ring
1
7006064
10
O-ring
1
7162075
11
Snap-on square Ø6
1
7010116
12
Membrane vent for unit ventilation
1
7162051
13
Screw for plastic for fixing the safety valve cover
1
7162057
14
Unit safety valve cover
1
7162056
15
Safety valve axle
1
7162053
16
Safety valve O-ring
1
7380165
17
Safety valve circlip
1
7162055
18
Safety valve spring
1
7162054
19
O-ring
1
7162076
20
O-ring
2
7380165
21
Non-detachable M8 CHC screw
2
7162058
22
M5 Washer
1
7162072
23
Screw for plastic for low fixing of the module on base
1
7162049
24
Screw for plastic for high fixing of the module on base
1
7162050
25
M3 Washer
1
7162073
