Definox Sorio - References and dimensions of cams, bases and spacers

MAINTENANCE NOTICE
NM-275 index 09 Page 44/50 September 2021
9.9 References and dimensions of cams, bases and spacers
9.9.1 Cams
Ref.
Visual
Cam
Tools
Height
H
Threading
F
Tapping
T
7162010
A
M6
Allen key 2.5
≥ 2 Nm
39
M6
7162011
A
M8
Allen key 2.5
≥ 2 Nm
43
M8
7162012
B
M10
Open-end
spanner 17
50
M10
7162013
B
M12
Open-end
spanner 17
50
M12
7162014
B
M16
Open-end
spanner 17
51
M16
7162138
C
M6 Female
Allen key 2.5
≥ 2 Nm
72
M6
7162189
C
M5 Female
Allen key 2.5
≥ 2 Nm
72
M5
7162201
B
M6 VDCI MC PFA DN38/51
Open-end
spanner 17
55
M6
7162202
B
M8 VDCI MC PFA DN63/125
Open-end
spanner 17
55
M8
7162241
B
M10 VDCI 95 DN80/104
Open-end
spanner 17
56,5
M10
7162242
B
M12 VDCI 95 DN125/150
Open-end
spanner 17
58,5
M12
