Rooster™ Sensor100 USER MANUAL
Rooster
TM
Sensor100 USER MANUAL 62320MN000-A04 15
Night Setback
The Rooster
TM
Sensor100 supports night setback (NSB) for energy savings and greater HVAC
system integration in building automation systems. Users can toggle between three modes of
operation detailed below:
*This crescent moon icon [ ] will appear on the top portion of the home screen when Night Setback is active*
Home>Settings>System>Alarms/Sound>Alarm Controls>Night Setback
Note: The definitions in the table below are with the I/O Polarity of the NSB input set as
normally open.
Night SetBack
Modes
Definition
Audible
Enters Night Setback mode whenever relay is closed and audibly triggers an alarm
when airflow drops below NSB trip point. To adjust Night Setback alarm thresholds,
you must go to the Threshold menu and select “Adjust Thresholds”.
Muted
Enters Night Setback mode whenever relay is closed and triggers a muted alarm when
airflow drops below the NSB trip point. (LED will still flash during an alarm event). This
is the default setting. To adjust Night Setback alarm thresholds, you must go to the
Threshold menu and select “Adjust Thresholds”.
Off
Disables Night Setback mode. Alarm does not enter Night Setback mode when relay is
closed.
Alarm Ringback
When an active alarm state is muted, ringback is a useful safety feature to remind the user that
the muted alarm is still active. Whenever there is an active alarm state, the red LED will flash for
the entire duration of the alarm. There are seven ringback modes available:
Home>Settings>System>Alarms/Sound>Alarm Controls>Ringback
Settings
Definition
Off
Disables ringback. If an alarm is muted, the alarm remains muted for the entire duration of
the alarm event.
10s
A muted alarm will ringback audibly after 10 seconds if the unit is still in an active alarm state.
This is the default setting.
30s
A muted alarm will ringback audibly after 30 seconds if the unit is still in an active alarm state.
1min
A muted alarm will ringback audibly after 60 seconds if the unit is still in an active alarm state.
5min
A muted alarm will ringback audibly after 5 minutes if the unit is still in an active alarm state.
10min
A muted alarm will ringback audibly after 10 minutes if the unit is still in an active alarm state.
60min
A muted alarm will ringback audibly after 60 minutes if the unit is still in an active alarm state.
