Airflow Settings
Airflow Sensitivity
This setting smooths airflow readings by applying a filter that determines “sensitivity” of
readings.
Home>Settings>System>Airflow Settings>Sensitivity
Sensitivity
Definition
Low
Increases filtering providing smoother readings, but slower response.
Med
Default setting. Provides a balance between smooth readings and reasonable response
times.
High
Decreases filtering resulting in greater fluctuation of readings with faster response.
Airflow Resolution
For advanced users, displayed velocity units can be configured to display in an alternate
resolution. The default resolution for units is 1 fpm and .01 m/s respectively, however, for users
who prefer a more uniform readout, this can be configured at different settings up to 5 fpm or
.05 m/s.
Home>Settings>System>Airflow Settings>Airflow Resolution
Airflow Resolution
Definition
1 fpm
Displayed units in FPM are rounded to 1 fpm. This is the default setting.
2 fpm
Displayed units in FPM are rounded to 2 fpm.
5 fpm
Displayed units in FPM are rounded to 5 fpm.
.01 m/s
Displayed units in m/s are rounded to .01 m/s. This is the default setting.
.02 m/s
Displayed units in m/s are rounded to .02 m/s.
.05 m/s
Displayed units in m/s are rounded to .05 m/s.
Volumetric Flow Settings
The Sensor100 displays velocity flow by default. Display of volumetric flow is available for
applications using the probe style sensor in a ducted flow. Volumetric flow can be displayed by
first navigating to the Airflow Settings menu to enable volumetric flow, and then entering the
required duct information. The steps are as follows:
1. Navigate to the System screen by following this path:
Home>Settings>System
