Events, Events Breakers
Description Notes
Mains fail Mains failure condition.
MB closed Mains breaker closed.
MB opened Mains breaker opened.
TB closed Tie breaker closed.
TB opened Tie breaker opened.
TB synchronising Tie breaker synchronising in progress.
MB synchronising Mains breaker synchronising in progress.
MB synchronisation to DG activated Mains breaker synchronisation activated.
MB synchronisation to DG deactivated Mains breaker synchronisation deactivated.
GB synchronisation to mains activated Generator breaker synchronisation activated.
GB synchronisation to mains deactivated Generator breaker synchronisation deactivated.
Events, Events Plant
Description
Notes
Application [1-4] activated Activate the application from the controller.
Single DG selected Single DG application selection.
Multi mains selected Multi-mains application selection.
Genset group selected Genset group application selection.
Genset group plant selected Genset group plant application selection.
Test application selected with output cmd
enabled
Emulation with engine and breaker relay reaction.
Test application selected with output cmd
disabled
Emulation without engine and breaker relay reactions.
Mode shift activated Mode shift between a running mode and AMF (Automatic Mains Failure) activated.
Mode shift deactivated
Mode shift between a running mode and AMF (Automatic Mains Failure)
deactivated.
Autoswitch off selected Autoswitch is not enabled.
Autoswitch static selected Autoswitch enabled for static section.
Autoswitch dynamic selected Autoswitch enabled for dynamic section.
Autoswitch all selected Autoswitch enabled for all sections.
MB parallel activated Multiple mains are allowed to supply the same busbar.
No break transfer activated No break transfer is active.
MB close failure start activated MB close failure start is active.
Inductive reference selected Inductive cos phi reference.
Capacitive reference selected Capacitive cos phi reference.
Events, Events Power management
Description
Notes
Capacity overrule active Power capacity overrule is active.
Capacitive overrule inactive Power capacity overrule is inactive.
Application note 4189341276B EN Page 21 of 50
