Description Notes
CIO 208 no. [1-3] Out. [9; 11; 13; 15;
18; 21; 24; 27]
Activates the relay if the Relay function is set to Limit relay.
Only visible if the CIO modules are enabled.
CIO [116; 208; 308] no. [1-3] conf.
status output
Activates the relay if the relay function is set to Limit relay and the relay type is
Configurable.
Only visible if the CIO modules are enabled.
4.16 Virtual events
Description Notes
Virtual event [1-96]
Virtual events 1 to 96 are used as connection between multiple logics to enhance the
possible number of events in one sequence.
4.17 AOP buttons
Description Notes
Button [01-08] The selected AOP button is activated.
More information
See Configuration Tools, Parameters, M-Logic & AOP in the USW Help for more information about configuring the AOP.
4.18 Fail class
Available fail classes for each controller type
Description
Genset Mains Bus tie breaker Group Plant Notes
Block ● ● ● ● ● Start blocking.
Warning ● ● ● ● ● Warning.
Trip GB ● Trip genset breaker.
Trip+stop ● Trip breaker, cool down and stop.
Shutdown ● Trip genset breaker and stop engine.
Trip MB ● ● ● Trip mains breaker.
Trip BTB ● Trip bus tie breaker.
Trip TB ● ● Trip tie breaker.
Safety stop ● ●
A failure condition is expected, and the generator will be taken
out for safety reasons. This feature is only useful in power
management.
Trip MB/GB ●
MB will be primary breaker to trip. If no MB is available in the
application, the GB will trip instead.
Controlled stop ● De-load genset, trip breaker, cool down and stop.
Trip MB/TB ●
First try to open the MB. If no MB exists, open the TB. If an MB
exists but is already open, do not open the TB.
4.19 Power management
More information
See Option G5 Power management for information.
Application note 4189341276B EN Page 30 of 50
