Description Notes
Test application selected with output cmd
disabled
Emulation without engine and breaker relay reactions.
BB Parameter set [1-2] used Nominal busbar settings 1 or 2.
Ethernet ready Ethernet is ready for read/write.
L1L2L3 phase rotation active The phase rotation is L1L2L3.
L1L3L2 phase rotation active The phase rotation is L1L3L2.
4.3.5 Plant controller events
Events for plant
Description
Notes
Mains fail Mains failure condition.
MB closed Mains breaker closed.
MB opened Mains breaker opened.
MB synchronising Mains breaker synchronising in progress.
Access lock Binary input access lock activated.
Emergency stop Emergency stop activated.
Lamp test Lamp test in progress.
Alternative start activated Alternative start is a full AMF sequence test of the plant.
Event log selected for printing Printer option: The Event log printout can be selected.
Alarm log selected for printing Printer option: The Alarm log printout can be selected.
Battery log selected for printing Printer option: The Battery log printout can be selected.
Parameter set [1-4] used The parameter set can be selected internally or with binary input.
Test type simple selected Selection of test type: Simple test.
Test type load selected Selection of test type: Load test.
Test type full selected Selection of test type: Full test.
BB voltage OK Busbar voltage OK.
Capacity overrule active Power capacity overrule is active.
Capacitive overrule inactive Power capacity overrule is inactive.
Application [1-4] activated Activate the application from the controller.
Single DG selected Single DG application selection.
Multi mains selected Multi-mains application selection.
Dynamic section equal static section Power management feature.
My ID to run selected Determines which mains feeder is allowed to operate parallel to the mains.
M volt/freq OK Mains frequency and voltage are within range.
Run one mains selected Only one mains breaker is allowed to be closed at the time.
Run all mains selected All mains breakers are allowed to be closed at the time.
Update mode local selected Update of setting on local controller.
Update mode on all selected Update of setting on all controllers.
Ack. all alarms active Acknowledge all active alarms.
MB synchronisation to DG activated Mains breaker synchronisation activated.
Application note 4189341276B EN Page 24 of 50
