5.7.2 CIO digital outputs
Only available if the CIO modules are enabled.
Description Notes
CIO 208 no. [1-3] Out. [9; 11; 13; 15;
18; 21; 24; 27]
Activates the relay if the Relay function is set to Limit relay.
Only visible if the CIO modules are enabled.
CIO [116; 208; 308] no. [1-3] conf.
status output
Activates the relay if the relay function is set to Limit relay and the relay type is
Configurable.
Only visible if the CIO modules are enabled.
5.8 Inhibits
Inhibits for each controller type
Description
Genset Mains
Bus tie
breaker
Group tie
breaker
Plant Notes
Activate LD stop used ●
Load-dependent stop. See Option G5.
Activate LD stop ●
Deactivate mode button ● ● ● ● ● Mode button on display front.
Activate MB synchronisation to
DG
● ● ●
Mains breaker synchronisation to the
genset(s) is activated.
Activate GB synchronisation to
mains
● ● ●
Generator breaker synchronisation to
the mains is activated.
Deactivate MB synchronisation
to DG
● ● ●
Mains breaker synchronisation to the
genset(s) is deactivated.
Deactivate GB synchronisation
to mains
● ● ●
Generator breaker synchronisation to
the mains is deactivated.
Inh. analogue load share ● Deactivate analogue load sharing.
Inh. acknowledge in AUTO ● ● ● ● ●
If in AUTO mode, the alarm
acknowledge is not possible.
Inh. Modbus commands ● ● ● ● ● Modbus commands are ignored.
Force DG in quarantine ●
Diesel generator will not participate in
power management.
Activate short time parallel ● ● ● Activate 1 s max. parallel time.
Deactivate short time parallel ● ● ● Deactivate 1 s max. parallel time.
Inhibit [1-3] ● ● ● ● ● Alarm inhibits.
Activate power management ● ●
Deactivate power management ● ●
Select multi-start set [1-2] ● ● ●
Selection of number of generators to
start on blackout.
Block priority swapping ● ● Present start priority list is maintained.
Activate mode shift ● ● ●
Activate shift from a running mode to
AMF in case of mains failure.
Deactivate mode shift ● ● ●
Deactivate shift from a running mode to
AMF in case of mains failure.
Inh. BTB close request ● ● ● ● Bus tie breaker closing not allowed.
Application note 4189341276B EN Page 46 of 50
