Description Notes
AVR decrease AVR voltage control output.
Freeze AVR regulation AVR voltage control output.
Freeze reactive power ramp Reactive power ramp control output.
Reset Analogue output (Gov & AVR) Resets the analogue governor or AVR output if it has been manually changed.
External power control CIO 308_1_8 Changes the analogue signal for power control to input 8 on CIO308.
External frequency control CIO
308_1_8
Changes the analogue signal for frequency control to input 8 on CIO308.
External voltage control CIO
308_1_11
Changes the analogue signal for voltage control to input 11 on CIO308.
External cos phi control CIO
308_1_11
Changes the analogue signal for cos phi control to input 11 on CIO308.
External reactive power control CIO
308_1_11
Changes the analogue signal for reactive power control to input 11 on CIO308.
5.15 EIC commands
These commands are only available for genset controllers.
More information
See Options H12 and H13 Engine communication for information.
5.16 DAVR commands
These commands are only available for genset controllers.
More information
See Configure the DVC 550 with the AGC-4, M-Logic related to DVC 550 in the DVC 550 Designer's handbook for
more information about DAVR commands.
5.16.1 DAVR PSS commands
Description Notes
Disable PSS Turn off the DAVR power system stabiliser function.
Enable PSS at GB pos ON The DAVR power system stabiliser function is enabled when the genset breaker is closed.
Enable PSS at mains parallel
The DAVR power system stabiliser function is enabled when the genset is parallel to the mains/
grid.
5.17 Flip flops
Description Notes
Flip flop set [1-16] The output is used to set the flip flop state.
Flip flop reset [1-16] The output is used to reset the flip flop state.
Flip flop toggle [1-16] The output is used to toggle the flip flop state.
5.18 Easy connect
These commands are only available for genset controllers.
Application note 4189341276B EN Page 49 of 50
