V0608, 2.7
parameters of these axes appear here.
2.3.3. Bend parameters - second page
2.e
This page contains the additional parameters of a bend.
Force. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..P
The required force during pressing (auto computed).
This force is precomputed from the bend properties Material, Thickness, Bending length
and the V-opening of the die.
Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..V
Working speed (pressing speed). Initially, the value for this parameter is copied from the
parameter ‘pressing speed’ in the programming constants menu.
Dwell time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..T
Holding time of punch at bending point.
Decompression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..DC
Decompression stroke after bending to release the working pressure
Decomp speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..BS
The decompression speed is the programmable speed which is active during the
programmed decompression stroke.
Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..CX
Programmable parameter which determines when the parameter values for the next
bending will be active. The possibilities are:
0 = Bending number change (step change) at end of decompression (next bend
