Delem DAC-310 - Function Outputs F; Repetition CY

DAC-310 Delem
V0504, 14
4.3.6. Function Outputs F
There are two function (on/off) outputs: F1 and F2.
The value of these two outputs can be programmed as one
parameter.
There are four combinations:
Value F2 F1
00 off off
01 off on
10 on off
11 on on
Default: 00 (both off)
A combination can be programmed with function F.
The digital outputs will be set to the programmed value when the
start-enable input becomes high while the DAC has been started.
The outputs stay at the actual value during the program step and
will be reset when the DAC is stopped.
Note: the presence of this parameter depends on machine
settings
4.3.7. Repetition CY
Step repetition: the number of times a step is repeated before the
next step is executed.
Range : 0 - 9999
Default: 1
Note 1:
The value 0 means that the step must be skipped.
Note 2:
This parameter has no meaning in Manual mode and is equal to
0.
Note 3:
The presence of this parameter depends on machine settings
