Steps
1. Disconnect the speaker cable from the system board.
2. Unroute and remove the speaker cable from the routing guides on palm-rest and keyboard assembly.
3. Lift the speakers, along with the cable, off the computer.
Installing the speakers
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the speakers and provides a visual representation of the installation procedure.
NOTE:
If the rubber grommets are pushed out when removing the speakers, push them back in before replacing the
speakers.
44 Removing and installing components
