1-6 Rack Installation Guide
Figure 1-4. Two-Post Flush-Mount Rack Kit Contents
Recommended Tools and Supplies
You need the following tools and supplies to install the system in a two-post open-
frame relay rack:
• #2 Phillips screwdriver
• Masking tape or a felt-tip pen, for use in marking the mounting holes to be used
flush-mount brackets (2)
10-24 x 0.25 inch flat-
head Phillips screws (4)
1-U template
inner mounting rails (2)
12-24 x 0.5-inch pan-
head Phillips screws (4)
2D786bk0.book Page 6 Thursday, January 18, 2001 8:44 PM
