1-2 Rack Installation Guide
Rack Kit Contents
The rack kit includes the following items (see Figure 1-1):
• Two center-mount brackets
• Four 10-24 x 0.375-inch pan-head Phillips (or slotted) screws
• Two 12-24 x 0.5-inch pan-head Phillips screws
Figure 1-1. Two-Post Center-Mount Rack Kit Contents
Recommended Tools and Supplies
You need the following tools and supplies to install the system in a two-post open-
frame relay rack:
• #2 Phillips screwdriver
• Masking tape or a felt-tip pen, for use in marking the mounting holes to be used
center-mount brackets (2)
12-24 x 0.5-inch pan-head
Phillips screws (2)
10-24 x 0.375-inch pan-
head Phillips screws (4)
