Dell 500 - Page 25

6. Remove the center control cover (see Removing the Center Control Cover).
7. Remove the keyboard (see
Removing the Keyboard).
8. Disconnect the display cable from the connector.
1 display cable
9. Pull the antenna cables from the routing hole and release them from the routing channel.
10. Remove the four screws from the display assembly hinges.
