3 keyboard tabs (5) 4 media control buttons connector
9. Lift the keyboard and hold it up and slightly forward to access the media control buttons connector.
10. Disconnect the media control buttons cable from the connector on the system board.
Replacing the Center Control Cover
1. Reconnect the media control buttons cable to the connector below the keyboard on the system board.
2. Align the tabs along the bottom of the keyboard and slide them under the palm rest.
3. Press on the right edge near the top to snap the keyboard into place.
4. Replace the two screws on the top of the keyboard.
5. Reconnect the media control buttons cable to the center control cover.
6. Place the center control cover in position and press from left to right until it snaps into place.
7. In the battery bay, replace the two screws that secure the center control cover.
