Component Secured to Screw type Quantity Screw image
Hard-drive assembly Palm-rest assembly M2.5x5 4
Hard-drive bracket Hard drive M3x3 4
Power-adapter port
bracket
Palm-rest assembly M2x3 1
Rear-I/O cover Computer base M2.5x2.5 4
Rear-I/O cover Palm-rest assembly M2.5x7 2
System board Palm-rest assembly M2.5x5 2
Solid-state drive Palm-rest assembly M2x3 2
Touchpad bracket Palm-rest assembly M2x3 5
Wireless-card bracket System board M2x3 1
15
