Replacing the macro keys
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
Insert the tabs on the top side of the macro keys into the slots on the palm-rest assembly. Ensure that the openings at the
bottom of the macro keys t into the studs on the palm-rest assembly.
Post-requisites
1 Replace the keyboard.
2 Replace the system board.
3 Replace the right power-adapter port.
4 Replace the heat-sink assembly.
5 Replace the computer base.
6 Replace the rear I/O cover
7 Follow the procedure from step 4 to step 7 in Replacing the hard drive.
8 Replace the wireless card.
9 Replace the solid-state drive.
10 Replace the memory modules.
94
