Dell Alienware Area-51m - Removing the Rear-I;O Cover

Removing the rear-I/O cover
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1 Disconnect the tron-light cable from the system board and peel it o from the computer base.
2 Remove the four screws (M2.5x2.5) that secure the rear I/O cover to the computer base.
3 Remove the two screws (M2.5x7) that secure the rear I/O cover to the palm-rest assembly.
4 Push the rubber feet on the rear I/O cover to remove it from the palm-rest assembly.
39
