Dell Alienware Area-51m - Replacing the Rear-I;O Cover

Replacing the rear-I/O cover
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the tabs on the rear I/O cover with the slots on the computer base and snap the rear I/O cover into place.
2 Replace the two screws (M2.5x7) that secure the rear I/O cover to the palm-rest assembly.
3 Replace the four screws (M2.5x2.5) that secure the rear I/O cover to the computer base.
4 Adhere the tron-light cable to the computer base and connect the tron-light cable to the system board.
Post-requisites
Replace the base cover.
40
