Removing the hard drive
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
CAUTION: Hard drives are fragile. Exercise care when handling the hard drive.
CAUTION: To avoid data loss, do not remove the hard drive while the computer is in sleep or on state.
Prerequisites
Remove the base cover.
Procedure
1 Using the pull tab, disconnect the hard-drive cable from the system board.
2 Remove the hard-drive cable from the routing guides on the computer base.
3 Remove the four screws (M2.5x5) that secure the hard-drive assembly to the palm-rest assembly.
4 Lift the hard-drive assembly along with its cable o the palm-rest assembly.
34
