Removing the display assembly
WARNING: Before working inside your computer, read the safety information that shipped with your computer and
follow the steps in Before working inside your computer. After working inside your computer, follow the instructions
in
After working inside your computer. For more safety best practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the rear-I/O cover.
Procedure
1 Remove the screw (M2x3) that secures the display-cable bracket to the system board.
2 Lift the display-cable bracket o the system board.
3 Using the pull tab, disconnect the display cable from the system board.
4 Disconnect the camera cable from the system board.
5 Peel o the display cable and the camera cable from the computer base.
6 Disconnect the tobii cable from the system board.
7 Remove the antenna cables from the routing guides on the computer base.
8 Peel o the tobii cable from the computer base.
52
