Steps
1. Connect the battery cable to the system board.
2. Slide the notches on the top of the base cover under the rear I/O-cover and snap the base cover into place on the palm-rest
assembly.
3. Tighten the six captive screws on the base cover.
4. Replace the two screws (M2.5x5) that secure the base cover to the palm-rest assembly.
Next steps
1. Follow the procedure in
After working inside your computer.
M.2 solid-state drive
Removing the M.2 2230 solid-state drive
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
13
