8. Replace the screw (M2x3) that secures the wireless-card bracket to the left I/O-board.
9. Adhere the Mylar over the system board and left I/O-board.
Next steps
1. Install the battery.
2. Install the
2230 solid-state drive. (if applicable)
3. Install the 2280 solid-state drive. (if applicable)
4. Install the base cover.
5. Follow the procedure in
After working inside your computer.
Right I/O-board
Removing the right I/O-board
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the 2230 solid-state drive. (if applicable)
4. Remove the 2280 solid-state drive. (if applicable)
5. Remove the battery.
About this task
The following image indicates the location of the right I/O-board and provides a visual representation of the removal procedure.
36
