2. Memory module
3. WLAN card
4. Solid-state drive
5. System board
6. Heat-sink
7. Chassis
8. Hard-drive assembly
9. Hard-drive cover
10. Solid-state drive in the hard-drive bay
11. Solid-state daughter board
12. System fan
13. Power button
14. Coin-cell battery
NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These
parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for
purchase options.
Hard-drive assembly
Removing the hard-drive assembly
Prerequisites
1. Follow the procedure in before working inside your device.
About this task
The figure indicates the location of the hard-drive assembly module and provides a visual representation of the removal
procedure.
Removing and installing components
13
