Dell D7523QT - Resolution and Video Capabilities

About your monitor | 13
Ports and connectors
1 x RS232 port
3 x HDMI 2.0 ports
1 x DisplayPort 1.2
3 x USB-A 3.1 Gen 1 downstream ports
2 x USB-A 2.0 downstream ports
1 x USB-B 3.1 Gen 1 upstream port
1 x RJ45 port
Border width (edge of monitor to active area)
Top/Left/Right
Bottom
16.3 mm (0.64 in.)
54.3 mm (2.14 in.)
Security
Security-lock slot (cable lock optional purchase)
Cable management Yes
Resolution specifications
Model D7523QT
Horizontal scan range 30 kHz to 160 kHz (automatic)
Vertical scan range 23 Hz to 75 Hz (automatic)
Maximum preset resolution 3840 x 2160 at 60 Hz
Support video mode
Model D7523QT
Video display capability
(HDMI & DP playback)
480p, 576p, 480i(HDMI only), 576i(HDMI only)
720p, 1080p, 1080i(HDMI only), 2160p
