Table 38. System board connectors (continued)
Item Connector Description
5 SATA_TBU Tape drive SATA connector
6 J_SATA_B SATA connector B
7 CTRL_PNL Control panel interface connector
8 J_SATA_A SATA connector A
9 INT_USB_3.0 Internal USB connector
10 TPM_MODULE Trusted Platform Module (TPM) connector
11 J_PSWD_NVRAM See System Board Jumper Settings
NOTE: With the system board in the above orientation:
Left jumper: PSWD jumper
Right jumper: NVRAM jumper
12 SLOT1 PCIE_G2_X4 (PCH) PCIe card connector 1
13 SLOT2 PCIE_G2_ X1 (PCH) PCIe card connector 2
14 SLOT3 PCIE_G3_X16
(CPU1)
PCIe card connector 3
15 SLOT4 PCIE_G3_X16
(CPU1)
PCIe card connector 4
16 SLOT5 PCIE_G3_X8
(CPU2)
PCIe card connector 5
17 SLOT6 PCIE_G3_X8
(CPU2)
PCIe card connector 6
18 BATTERY System battery
19 FAN1 Internal cooling fan connector
20 FAN2 External cooling fan connector
21 B1, B2 Memory module sockets
22 J_AMEA Advanced Management Enablement Adapter (AMEA) connector
23 B4, B3 Memory module sockets
24 CPU2 Processor 2
25 PWR_CONN_C (P3) CPU2 power connector
26 CPU1 Processor 1
27 IDSDM Internal dual SD module connector
28 INTRUSION Intrusion switch connector
29 A1, A5, A2, A6 Memory module sockets
30 PWR_CONN_B (P2) CPU1 power connector
31 A8, A4, A7, A3 Memory module sockets
32 ACT_LED Front-panel hard-drive LED controller connector
33 BP_SIG Backplane signal connector
34 ODD_PWR Optical drive power connector
Jumpers and connectors 177
