Dell E30S Series

Table 15. Dimensions of Dell PowerEdge T430 system
System X Xa Y Ya Yb Z Za Zb
PowerEdge
T430
304.5 mm
(11.99
inches)
218 mm
(8.58
inches)
471.3 mm
(18.55
inches)
430.3 mm
(16.94
inches)
443.3 mm
(17.45
inches)
594.82 mm
(23.42
inches)
578.42 mm
(22.77
inches)
542.2 mm
(21.35
inches)
Chassis weight
Table 16. Chassis weight
System Maximum weight
PowerEdge T430
36 Kg (79.37 lb)
Processor specifications
The PowerEdge T430 system supports up to two Intel Xeon E5-2600 v4 or Xeon E5-2600 v3 product family processors.
PSU specifications
The PowerEdge T430 system supports up to two AC or DC redundant power supply units (PSUs).
Table 17. PSU specifications
PSU Class Heat dissipation
(maximum)
Frequency Voltage
450 W AC Bronze 1871 BTU/hr
50/60 Hz
100 – 240 V AC, 6.5 A – 3.5 A, autoranging
495 W AC Platinum 1908 BTU/hr 100 – 240 V AC, 6.5 A – 3 A, autoranging
750 W AC Platinum 2891 BTU/hr 100 – 240 V AC, 10 A – 5 A, autoranging
1100 W AC Platinum 4100 BTU/hr 100 – 240 V AC, 12 A – 6.5 A, autoranging
NOTE: Heat dissipation is calculated using the PSU wattage rating.
NOTE: This system is also designed to connect to the IT power systems with a phase-to-phase voltage not exceeding 230
V.
System battery specifications
The PowerEdge T430 system supports CR 2032 3.0-V lithium coin cell system battery.
Expansion bus specifications
The PowerEdge T430 system supports PCI express (PCIe) generation 3 and 2 expansion cards. The following table describes
the supported expansion cards:
Table 18. Supported PCI express generation 3 expansion cards
PCIe Slot Processor Connection Height Length Link Width Slot Width
1 (Gen2) Platform Controller Hub Full height Half Length x4 x8
2 (Gen2) Platform Controller Hub Full height Half length x1 x1
32 Technical specifications
