A–1
A Array Technical Specifications
Table A-2 describes the environmental, power, and physical specifications for a PS6500 array.
Table A-2: PS6500 Technical Specifications
Component Requirement
Weight without disk drives 35 kg (77 lb)
Weight with disk drives 80 kg (177 lb)
Operating temperature 5 to 35 ºC (41 to 95 ºF)
Storage temperature 1 to 60 ºC (34 to 140 ºF)
Maximum operating altitude 0 to 3048 meters (0 to 10,000 feet)
Operational relative humidity 20% to 80% noncondensing
Storage relative humidity 5% to 80% noncondensing
Thermal output (fully-loaded array) 3400 BTU/hour
Operational shock 5g peak 1/2 sin, for 10ms
Operational vibration .21 G
rms
5 to 500 Hz Random
Input voltage 100 to 240 VAC (auto-sensing)
Input frequency 50 - 60 Hz
System input power 1400 VA (maximum)
Each power supply 440 watts DC output
Maximum input power: 0.7 KVA
Input current: 7 – 3.5A
Chassis dimensions 17.5 cm by 48.3 cm by 81.0 cm
(6.89 in. by 19.01 in. by 31.90 in.)
