Installing battery
1 Insert the battery into the slot on the computer.
2 Connect the battery cable to the connector on the system board.
3 Replace the 4 (M1.98 x 4L) screws to secure the battery to the computer.
4 Install the:
a Base cover
b SIM card tray
c MicroSD card
NOTE
: To install both cards if equipped.
5 Follow the procedure in After working inside your computer.
PCIe Solid State Drive (SSD)
Removing the NVMe SSD card
1 Follow the procedure in Before working inside your computer.
2 Remove:
a MicroSD card
b SIM card tray
NOTE
: To remove both cards if equipped and no need to remove the blank ller
c Base cover
d Battery
3 To remove the NVMe SSD card:
a Loosen the 2 (M2.0 x 3.0) screws that secure SSD thermal plate in place [1].
Removing and installing components
11
