Dell Latitude 7390 2-in-1 User Manual

Installing the ngerprint reader board
1 Install the ngerprint reader board into the slot.
2 Place the ngerprint reader bracket on the board.
3 Replace 1(M2 x 3) screw to secure the bracket to the board.
4 Connect the ngerprint reader cable to the ngerprint reader board and the USH board.
5 Ax the coin cell battery on the speaker cable
6 Install the:
a Battery
b Base cover
c SIM card tray
d MicroSD card
NOTE
: To install both cards if equipped.
7 Follow the procedure in After working inside your computer.
LED Board
Removing the LED board
1 Follow the procedure in Before working inside your computer.
2 Remove:
a Micro SD
b SIM card tray
NOTE
: To remove both cards if equipped and no need to remove the blank ller
Removing and installing components 21

Dell Latitude 7390 2-in-1 Specifications

General

Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Pro
Processor	8th Generation Intel Core i5/i7
Display	13.3-inch FHD (1920 x 1080) touch screen
RAM	8GB or 16GB LPDDR3
Storage	Up to 1TB PCIe SSD
Battery	4-cell 60Whr
Weight	1.42 kg (3.12 lbs)
Ports	1 x microSD card reader, 1 x headphone/microphone combo jack
Wireless	Intel Dual Band Wireless-AC 8265, Bluetooth 4.2
Webcam	720p
