Dell Latitude 7390 2-in-1 User Manual

b Lift the thermal plate from the SSD card [2].
c Remove the SSD card from the slot [3].
Installing the NVMe SSD
1 Insert the NVMe SSD card into the connector.
2 Install the thermal plate over the SSD card.
3 Tighten the 2 (M2.0 x 3.0) screws to secure the SSD thermal plate.
4 Install the:
a Battery
b Base cover
c SIM card tray
d MicroSD card
NOTE
: To install both cards if equipped.
5 Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1 Follow the procedure in Before working inside your computer.
2 Remove:
a MicroSD card
b SIM card tray
NOTE
: To remove both cards if equipped and no need to remove the blank ller
c Base cover
12
Removing and installing components

Dell Latitude 7390 2-in-1 Specifications

General

Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Pro
Processor	8th Generation Intel Core i5/i7
Display	13.3-inch FHD (1920 x 1080) touch screen
RAM	8GB or 16GB LPDDR3
Storage	Up to 1TB PCIe SSD
Battery	4-cell 60Whr
Weight	1.42 kg (3.12 lbs)
Ports	1 x microSD card reader, 1 x headphone/microphone combo jack
Wireless	Intel Dual Band Wireless-AC 8265, Bluetooth 4.2
Webcam	720p
