5 Lift the base of the computer away from the display assembly.
6 To remove the display assembly:
a Place the base of the computer with the display assembly.
NOTE
: To open as shown in the illustration.
b Remove the 4 (M2.5 x 4.0) screws that secure the display hinge brackets [1].
c Lift the display assembly away from the computer [2].
Removing and installing components
25

Dell Latitude 7390 2-in-1 Specifications

General

Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Pro
Processor	8th Generation Intel Core i5/i7
Display	13.3-inch FHD (1920 x 1080) touch screen
RAM	8GB or 16GB LPDDR3
Storage	Up to 1TB PCIe SSD
Battery	4-cell 60Whr
Weight	1.42 kg (3.12 lbs)
Ports	1 x microSD card reader, 1 x headphone/microphone combo jack
Wireless	Intel Dual Band Wireless-AC 8265, Bluetooth 4.2
Webcam	720p
