 Specifications
Dell™Latitude™E6410/E6410ATGServiceManual

SystemInformation
Fingerprint Reader (Optional)
Processor
PortsandConnectors
Memory
Drives
Video
Display
Audio
Keyboard
Communications
Touchpad
ExpressCard
Battery
PC Card
ACAdapter
Secure Digital (SD) Memory Card Reader
Physical
Contactless Smart Cards (Optional)
Environmental
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start® Help and Support and select the
option to view information about your computer.
SystemInformation
Chipset
Mobile Intel
®
5 series chipset (QM57)
Data bus width
64 bits
DRAM bus width
dual-channel 64 bits

NOTE: You must install memory in pairs for the dual
channel mode to work.
Flash EPROM
SPI 32 Mbits
PCI bus
32 bits, 33 MHz
Processor
Types
IntelCore™i5series
Intel Core i7 series
L2 cache
Intel Core i5-520M/540M Dual Core — 3 MB
Intel Core i7-620M Dual Core — 4 MB
External bus frequency
1066 MHz
Memory
Type
DDR3 SDRAM
Speed
1066 MHz
Connectors
two SODIMM connectors
Module capacities
1 GB, 2 GB, 4 GB
Minimum memory
1 GB
Maximum memory
8 GB

NOTE: Only 64-bit operating systems can detect
memory capacities greater than 4 GB.
Video
Type
E6410 — UMA or Discrete video controller
E6410 ATG — UMA
Controller

UMA
Intel Graphics Media Accelerator HD
Discrete
NVIDIA Quadro NVS 3100M
Output
15-pin VGA connector
20-pin DisplayPort connector

NOTE: DisplayPort, DVI, and VGA is offered through
the docking station.
Audio
Type
two-channel high-definition audio codec (HDA)
Controller
IDT 92HD81B Controller
Speaker
two
